PA DB12 SPM

Single Point Mooring Rope — OCIMF SPM Hawser Guidelines

The NWBS and energy-absorption characteristics of an SPM hawser degrade progressively with service life and cyclic load handling. PA DB12 SPM answers this with an engineered dual-component construction of high-performance polyamide 6.6 fibres — 12-strand braided core with a polyamide braided cover — for advanced offshore loading & unloading in all weather conditions.

PA 6.6fibre
2×grommet MBL
OCIMFSPM guidelines
All-weatherloading duty
Request a QuoteSize it in the toolsDatasheet (PDF)
Technical Data

Specification

Fitted with D-shackles, cast thimbles, PU coating and buoyancy floats per the OCIMF SPM layout. Single-leg and grommet MBLs (NDBS/NWBS) by diameter below.

Fibre & properties

Construction12-strand braided core + cover
FibrePolyamide 6.6
Specific gravity1.14 (sinking)
Melting point215 °C
Elongation15–28%
StandardOCIMF SPM Hauser Guidelines
Primary applications
Single Point MooringTanker Loading/UnloadingOffshore Terminals
Standards & approvals
OCIMF SPM Hauser GuidelinesISO 2307
Why PA DB12 SPM? Why PA DB12 SPM? Tested and manufactured to the OCIMF SPM hawser guidelines, with grommet constructions at twice the single-leg MBL — the configuration terminal operators audit against.
PA DB12 SPM™ — Performance Data
SPM Hawser

PA DB12 SPM™ — Performance Data

NDBS: New Dry Breaking Strength · NWBS: New Wet Breaking Strength (specific gravity of sea water assumed 1.025). Single-leg and grommet constructions, by diameter.

OCIMF SPM Hauser Guidelines

Fibre & properties

Construction12-strand braided core + PA cover
MaterialPolyamide 6.6
Specific gravity1.14 — sinks
Melting point215 °C
Breaking elongation15–28%
FittingsD-shackle · cast thimble · PU coat · floats

PA DB12 SPM — single & grommet MBL (NDBS / NWBS) by diameter

Dia mmDia inchCirc inchkg/100mlbs/100ftSingle NDBS tNDBS kNNWBS tNWBS kNGrommet NDBS tNDBS kNNWBS tNWBS kN
48261551046159755539103100993909
562-1/47213143807847270613613321231201
642-5/8827718610410199491817617241591554
72393372261291264116113921921461971934
803-1/4104072731551519140136826325772372322
883-5/8114913301861822168164231630962852790
964125853932232185201196937937143413346
1044-1/4136944662632577237232244743804033946
1124-5/8148005373012949271265751150074604512
1205159296243483410314307259157915325218
1285-1/41610507053893812350343466164775955836
1365-5/81712088114474380403394675974386846701
14461813328944954851446437084182417587425
1526-1/41914749905415301487477691990068288114
1606-5/8201647110659458215355244100998889098908
168721180412116616477595582711241101510129918

Customized diameter and length available on request · Tolerance ±5% per ISO 2307 · LDBF: Line Design Break Force per OCIMF MEG4.

Range

PA DB12 SPM configurations

Every hawser is configured to the OCIMF SPM layout with single-leg or grommet construction.

Single Leg
single leg

Single Leg

Standard hawser

12-strand braided core with PA cover, PU-coated thimble and D-shackle.

Grommet
grommet

Grommet

2× single-leg MBL

Doubled construction doubles the new dry breaking strength.

Fittings & Floats
floats + thimble

Fittings & Floats

OCIMF SPM layout

Cast thimble, PU coating, whipping, lace and buoyancy floats.
